Hand wash basin with rear wall (2 autom. dispenser+Dyson Tap)
Hand wash basin with rear wall (2 autom. dispenser+Dyson Tap)
Cleancenter
Type CC-I-DT / CC-II-DT
Controlled hand hygiene in forced sequence with hand drying
- Optionally for wall mounting or with feet
- Wall-mounted with 400 mm high splash protection wall
- Touch-free water outlet tap incl. hand dryer function, Dyson-Tap (WD06)
- Hygienic thanks to HEPA technology
- Drying time: 14 seconds
- 2 touchless taps for soap and disinfectant application
- Continuously adjustable sensor range and application quantity
- LED signal indicators for each touchless tap
- Base cabinet with cover, lockable using stainless steel sash lock
- Base cabinet for safe storage of canisters and Dyson WD06 technology
- Two operating modes for customised hygiene concepts selectable via Siemens LOGO!
- Thermostatic mixing valve incl. non-return valve
No product in the request list!
Please select the desired article on the gray field next to the article no. by clicking the mouse.
No product in the Quick inquiry list!
Please select the desired article on the gray field next to the article no. by clicking the mouse.
Subject to errors and technical changes. Supplied without soap and disinfectant.
Material
Manufactured from stainless steel 18/10 material no. 1.4301.
The externally visible stainless steel sheet surfaces have a polished finish with 320 grit.
The externally visible stainless steel profile surfaces, such as the feet, have a uniform brushed finish.
Description
The Cleancenter CC-I DT and CC-II DT combine a Dyson Tap “wash+dry” (WD06) water-saving wall-mounted tap with integrated hand drying directly at the basin with touch-free applicators for soap and/or disinfectant.
- Hand hygiene at the wash basin: washing and drying in one step with WD06, without dripping.
- Variants:
- CC-I DT: two touchless fittings for 2-hand soap application.
- CC-II DT: one touchless fitting each for soap and disinfectant.
- Use & selection: Depends on the hygiene concept of the staff hygiene lock and the planned extensions.
- Example process: With CC-I DT, separate hand disinfection takes place after washing – ideally controlled by a two-hand disinfection machine with an electric turnstile for secure access authorization.
The CC-I DT and CC-II DT Cleancenter models combine efficient washing/drying with flexible product variants – tailored to the respective hygiene workflow.
Advantages
- Touch-free infrared activation
- Automatic switch-off after 30 seconds
- Automatic rinse function 24 hours after last use for 60 seconds
- HEPA filter, removes 99.9 % of bacteria from the air
- Lower operating costs
- Reduced environmental impact
TIME/COST SAVINGS
- No need to buy additional paper towels
- and therefore no time spent on purchasing due to constant research into purchasing situations + processing required
- No more staff required for cleaning + disposal
- Inventory control in the warehouse and in EVERY towel dispenser no longer necessary
- No more quantity purchases necessary - therefore no liquidity burden
- No more pallet storage spaces required for paper stocks
IMAGE GAIN
Huge savings by avoiding CO2 emissions.
Technical progress is projected by using the Dyson hand dryer
CLEANLINESS
Avoidance of wet, unsightly scraps of paper in staff hygiene rooms, toilets etc., thus making a better impression when visiting customers etc.
Warranty / Guarantee
12-month warranty
60-month warranty (Dyson Tap type WD06 only)*
Technical Data
| Power supply | 230 V 1-N/PE; 50-60 Hz |
|---|---|
| Operating voltage | 24 V, DC |
| Performance | 0,1 kW |
| Drain | 1 1/2" |
| Water connection | 1/2" on the pre-mixer (HW/KW), working pressure 2.5 - 6 bar |
| Fusing | 16 A |
