4 compartments on top of each other -with feet

Compartment cupboards
Type FS4-AF-VA-EU-G

Compartment cupboard with doors regarding EU Directive

  • Execution with 4 height-adjustable standing feet, ground clearance 150 mm
  • Robust construction completely made of stainless steel
  • 2 compartment width (300 respectively 400 mm) available
  • With 4 compartments on top of each other
  • Single-wall doors, smooth without label frame
  • Right hinged doors, mounted on pivot pins
  • Doors lockable with cylinder lock incl. 2 keys
  • Shelf clear dimension: W 230 resp. 330 x D 465 x H 375 mm
  • Integrated pitched roof (200 mm higher at the back)
  • Smooth shelf with ventilation holes

TypeCompartment
persons
Width of compartmentsDimensions
W x D x H in mm
ComparePDF
FS4-AF-VA-EU-G 1/31 compartments a 4-person - 4 compartments300 mm320 x 500 x 1850/205045.10.05.3045.10.05.30
FS4-AF-VA-EU-G 1/41 compartments a 4-person - 4 compartments400 mm420 x 500 x 1850/205045.10.05.3145.10.05.31
FS4-AF-VA-EU-G 2/32 compartments a 4-person - 8 compartments300 mm610 x 500 x 1850/205045.10.05.3245.10.05.32
FS4-AF-VA-EU-G 2/42 compartments a 4-person - 8 compartments400 mm810 x 500 x 1850/205045.10.05.3345.10.05.33
FS4-AF-VA-EU-G 3/33 compartments a 4-person - 12 compartments300 mm900 x 500 x 1850/205045.10.05.3445.10.05.34
FS4-AF-VA-EU-G 3/43 compartments a 4-person - 12 compartments400 mm1200 x 500 x 1850/205045.10.05.3545.10.05.35
FS4-AF-VA-EU-G 4/34 compartments a 4-person - 16 compartments300 mm1190 x 500 x 1850/205045.10.05.3645.10.05.36
Special dimensions
Cylinder lock locking system00010010
Main key locking system 00001200
Number plate sticker04800701
Number plate made of stainless steel 85010611
We manufacture individually according to customer requirements

No product in the request list!

Please select the desired article on the gray field next to the article no. by clicking the mouse.

0
1780
1504
8
Show Lightbox Compare
Comparedata

Material

Stainless steel furniture made of chrome-nickel steel 18/10 material no. 1.4301.
The stainless steel sheet surfaces being visible from the outside are in polished finish with grain 320.
The externally visible stainless steel profile surfaces, such as stand feet have a uniform brushed finish



Options

  • Cylinder lock locking system, art.-no. 00.01.00.10
  • Main key locking system, art.-no. 00.00.12.00
  • Number plate sticker, art.-no. 04.80.07.01
