Locker
Type GS1-AF-VA-EU
Self-ventilation concept according to EU Directive and §34 Workplace Ordinance
- Execution with 4 height-adjustable feet (+/- 15 mm), ground clearance 150 mm
- Robust construction completely made of stainless steel
- 2 compartment width (300 respectively 400 mm) available
- Integrated pitched roof (200 mm higher at the back)
- Outside of the door with imprint for name plate
- Inside door with box profile reinforcement for maximum stability
- Doors perforated (square perforation)
(Hole pattern beginning underneath the hat shelf › private area!) - Right hinged doors, mounted on pivot pins
- Twist-lock catch for padlock (on the part of the building site)
- Every compartment with hat shelf, clothes rail + 3 slide bars
- With centre partition for S/W separation
(only with compartment width 400 mm) - Smooth shelf with ventilation holes
No product in the request list!
Please select the desired article on the gray field next to the article no. by clicking the mouse.
Material
Stainless steel furniture made of chrome-nickel steel 18/10 material no. 1.4301.
The stainless steel sheet surfaces being visible from the outside are in polished finish with grain 320.
The externally visible stainless steel profile surfaces, such as stand feet have a uniform brushed finish
Please note
Cloakroom lockers with a compartment width of 400 mm in combination with a centre partition per compartment are not compliant with the workplace directive (ASR Section 5 ASR 34/1-5 - Equipment of changing rooms). This option of a centre partition is merely a compromise solution for confined spaces.
Options
- Padlock (brass), art.-no. 00.00.02.10
- Mechan. combination lock, art.-no. 04.80.07.04
- Cylinder lock, simple, art.-no. 00.00.08.70
- Cylinder lock locking system, art.-no. 00.01.00.10
- Main key locking system, art.-no. 00.00.12.00
- Plastic shoe shell, art.-no. 04.50.07.07
- Number plate sticker, art.-no. 04.80.07.01
- Number plate made of plastic, art.-no. 85.02.06.11
- Number plate made of stainless steel, art.-no. 85.01.06.11
